HIKVISION DVR καταγραφικό HiWatch HWD-5116MH-G3, H.265+, 16 κανάλια
Υβριδικό DVR καταγραφικό 5 σε 1 (HDTV, AHD, CVI, CVBS, IP video input) της σειράς HiWatch από την HIKVISION. Υποστηρίζει έως και 16 αναλογικά κανάλια ή 18 κανάλια IP με ανάλυση εγγραφής 1080p και κωδικοποίηση βίντεο H.265 Pro+. Επιπλέον υποστηρίζει HDD έως 10ΤΒ.
-H.265 Pro+/H.265 Pro/H.265 video compression
-HDTVI/AHD/CVI/CVBS/IP video input
-Audio via coaxial cable
-Up to 18-ch IP camera input (up to 5 MP)
-Max. 800 m for 1080p and 1200 m for 720p HDTVI signal transmission
-Up to 10 TB capacity per HDD
-Support Turbo HD video input
-Two-way audio
-HDMI & VGA output
-Multi-channel synchronous playback
-High definition real-time recording
-Live view from smart device or Internet
-Easy smart search for motion event during playback
-Hik-connect P2P function for easy remote management
Τεχνικά χαρακτηριστικά
Video compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Encoding resolution: 1080p lite/720p/VGA/WD1/4CIF/CIF
Frame rate
Main stream: For 1080p stream access: 1080p lite/720p lite/WD1/4CIF/VGA @15fps; CIF @25fps
(P)/30fps (N), For 720p stream access: 720p/WD1/4CIF/VGA @15fps; CIF @25fps (P)/30fps (N), For standard definition stream access: WD1/4CIF/VGA/CIF @25fps (P)/30fps (N)
Sub-stream: For 1080p and 720p stream access: CIF/QVGA @15fps, For standard definition stream access: CIF/QVGA @25fps (P)/30fps (N)
Video bit rate: 32 Kbps to 4 Mbps
Dual stream: Support
Stream type: Video, Video & Audio
Audio compression: G.711u
Audio bit rate: 64 Kbps
IP video input: 2-ch (up to 18-ch), Up to 5 MP resolution, Support H.265+/H.265/H.264+/H.264 IP cameras
Analog video input: 16-ch, BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDTVI input: 1080p25, 1080p30, 720p25, 720p30
AHD input: 1080p25, 1080p30, 720p25, 720p30
HDCVI input: 1080p25, 1080p30, 720p25, 720p30
CVBS input: PAL/NTSC
HDMI/VGA output: 1-ch, 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz
Audio input: 1-ch, RCA (2.0 Vp-p, 1 KΩ), and 16-ch via coaxial cable
Audio output: 1-ch, RCA (Linear, 1 KΩ)
Two-way audio: 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
Synchronous playback: 16-ch
Remote connections: 128
Network protocols: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™,
HTTPS, ONVIF
Network interface: 1 RJ45 10M/100M self-adaptive Ethernet interface
SATA: 1 SATA interface
Capacity: Up to 10 TB capacity for each disk
USB interface: 2x USB 2.0
Power supply: 12 VDC, 1.6 A
Consumption (without HDD): Up to 10 W
Working temperature: -10°C to 55°C
Working humidity: 10% to 90%
Dimension (W x D x H): 260 x 222 x 45 mm
Περιεχόμενα συσκευασίας
DVR καταγραφικό
Ενσύρματο ποντίκι
Αντάπτορας τροφοδοσίας
Καλώδια σύνδεσης
Βίδες
Εγχειρίδιο χρήσης
